OpenMV Thermopile Shield
$100.00
The Thermopile Shield gives your OpenMV Cam the ability to see heat. It features a 16×4 60°x16° field-of-view (FOV) sensor array capable of measuring object temperatures between -50˚C to 300˚C while measuring the room temperature (between -40˚C to 85˚C).
Description
Description
Thermal Imaging Expansion Board your OpenMV provides the ability to view calories. It has a 16×4 60°x16° field of view (FOV) sensor array capable of measuring the temperature of an object between 85˚c and -50˚C while measuring room temperature ( -40˚C to 300˚C). The OpenMV firmware comes with a drive and can use the FIR module to control the Thermal Imaging expansion board.
Applications
The Thermopile Shield is great for temperature measurement applications or security applications. For example, you can use the Thermopile Shield with your OpenMV Cam to detect the presence of heat which will allow you to detect if there is a person in the field-of-view. This makes the Thermopile Shield excellent for detecting people in pitch black.
Specifications
| Length | 36mm |
| Width | 33mm |
| Height | 24mm |
| Weight | 5.5g |
Pinout
Schematic
Circuit diagram (PDF): thermal.pdf
Eagle File: (Thermal.sch thermal.brd)
